Simplicity CFC 16


Simplicity CFC 16 lawn tractor photo
1990 - 1994
CFC Series
Front-mount mower
Production
ManufacturerSimplicity
Front-mount mower
Original price was $6,500 in 1992
Variants
CFC 16steering wheel
CFC 16Llever steer
Simplicity CFC 16 Engine
16HP Briggs & Stratton 480cc 2-cyl gasoline
Fuel tank4 gal (early)
15.1 L
 5.7 gal (late)
21.6 L
Engine details ...
Mechanical
Drive3x1 2WD
Power steering
Mechanical band brakes
Open operator station.
Power Take-off (PTO)
Front PTOindependent
Clutchmechanical idler pulley
Dimensions & Tires
Weight640 lbs
290 kg
Front tire18x9.50-8
Rear tire13x5.00-6
Full dimensions and tires ...
Simplicity CFC 16 attachments
46" front-mount mower deck
54" front-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging amps16
Battery CCA340
Battery volts12
