Lawn Tractors > Simplicity > Broadmoor 16HV

Simplicity Broadmoor 16HV



Simplicity Broadmoor 16HV lawn tractor photo
2003 - 2004
Broadmoor Series
Lawn tractor
Production
ManufacturerSimplicity
Lawn tractor
Simplicity Broadmoor 16HV Engines
16HP Briggs & Stratton 480cc 2-cyl gasoline
16HP Honda 530cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Simplicity Broadmoor 16HV Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Simplicity Broadmoor 16HV are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase52 inches
132 cm
Weight690 lbs
312 kg
Front tire15x6.0-6
Rear tire20x10-10
Full dimensions and tires ...
Simplicity Broadmoor 16HV attachments
38" mid-mount mower deck
40" mid-mount mower deck
44" mid-mount mower deck
Attachment details ...
References
Broadmoor 16HV references literature
The Way To A Beautiful Lawn published in 2003, by Simplicity
The Way To A Beautiful Lawn published in 2004, by Simplicity
