Lawn Tractors > Toro > 770

Toro 770



Toro 770 lawn tractor photo
1970 - 1973
Lawn tractor
Series map:
700
770
7.0hp
7.0hp
Production
ManufacturerToro
Lawn tractor
Variants
700manual recoil start
770electric start
Toro 770 Engine
7HP Tecumseh 245cc 1-cyl gasoline
Fuel tank0.9 gal
3.4 L
Engine details ...
Toro 770 Transmission
3-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Photos
No photos of the Toro 770 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear PTOindependent
Dimensions & Tires
Wheelbase39 inches
99 cm
Weight290 lbs
131 kg
Front tire11x4.00-5
Rear tire15x6.00-6
Full dimensions and tires ...
Toro 770 attachments
32" mid-mount mower deck
blade
Attachment details ...
770 Serial Numbers
1970000001 (57204)
1971100001 (57222)
1972200001 (57228)
1973300001 (57228)

FAQ: How to read a serial number table.
Electrical
Groundnegative
Battery volts12
