John Deere LR135


John Deere LR135 lawn tractor photo
2004 - 2010
LR Series
Rear-discharge mower
Production
ManufacturerJohn Deere
Rear-discharge mower
John Deere LR135 Engine
10.1KW Briggs & Stratton 344cc 1-cyl gasoline
Fuel tank1.6 gal
6.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Disc on transmission brakes
Open operator station.
Dimensions & Tires
Wheelbase45.6 inches
115 cm
Weight423.3 lbs
192 kg
Front tire15x5.00-6
Rear tire18x8.50-8
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
Battery AH18
References
LR135 references literature
CR/LR Series Rear Discharge Riders & Lawn Tractors published by John Deere
Walk Behind Mower & Lawn Tractor Range published in 2011, by John Deere
