John Deere CR125


John Deere CR125 lawn tractor photo
2004 - ????
CR Series
Riding lawn mower
Production
ManufacturerJohn Deere
Riding lawn mower
John Deere CR125 Engine
9.3KW Briggs & Stratton 344cc 1-cyl gasoline
Fuel tank1.06 gal
4.0 L
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Disc on transmission brakes
Open operator station.
Photos
No photos of the John Deere CR125 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Wheelbase44.5 inches
113 cm
Weight363.8 lbs
165 kg
Front tire11x4.00-4
Rear tire15x6.00-6
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
Battery AH18
References
CR125 references literature
CR/LR Series Rear Discharge Riders & Lawn Tractors published by John Deere
Walk Behind Mower & Lawn Tractor Range published in 2011, by John Deere
The Complete Range of Lawn Care Solutions published in 2014, by John Deere
