Power King 1616


Power King 1616 lawn tractor photo
1977 - 1983
1600 Series
Garden tractor
Production
ManufacturerPower King (a part of Engineering Products Company)
Garden tractor
Built in Waukesha, Wisconsin, USA
Power King 1616 Engine
16HP Briggs & Stratton 531cc 1-cyl gasoline
Engine details ...
Power King 1616 Transmissions
3-speed gear
4-speed gear
9-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Final drivesbull gear
Manual steering
Mechanical drum brakes
Open operator station. Vinyl weather cab optional.
Capacity
Fuel3 gal
11.4 L
Hydraulic system5 gal
18.9 L
Hydraulics
Typeopen center
Capacity5 gal
18.9 L
Pressure1000 psi
69.0 bar
Pump flow1.7 gpm
6.4 lpm
Tractor hitch
Rear Type0 OptOptional
Power Take-off (PTO)
Rear PTOindependent OptOptional
Clutchelectro-magnetic
Rear RPM2000
Front PTOindependent
Clutchelectro-magnetic
Dimensions & Tires
Wheelbase54.375 inches
138 cm
Weight958 to 975 pounds
Front tire4.00-12
Rear tire8.00-16
Full dimensions and tires ...
Power King 1616 attachments
48" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
1616 Serial Numbers
Location:Serial number decal on tractor dashboard and front of hood.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery volts12
References
1616 references literature
Power King - One Tough Tractor published in 1980, by EPCO
