Power King 1617


Power King 1617 lawn tractor photo
1984 - 1988
1600 Series
Garden tractor
Series map:
1617
17.0hp
Production
ManufacturerPower King (a part of Engineering Products Company)
Garden tractor
Built in Waukesha, Wisconsin, USA
Power King 1617 Engine
17HP Kohler 691cc 2-cyl gasoline
Fuel tank8.25 gal
31.2 L
Engine details ...
Mechanical
Two-wheel drive
Final drivesspur bull gears
Steeringmanual
Open operator station.
Photos
No photos of the Power King 1617 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type0 (optional)
Power Take-off (PTO)
Rear PTOindependent (optional)
Rear RPM2000
Front PTOindependent
Clutchelectro-magnetic
Dimensions & Tires
Wheelbase57 inches
144 cm
Weight979 lbs
444 kg
Front tire8.0-10
Rear tire8.0-16
Full dimensions and tires ...
Power King 1617 attachments
48" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
1617 Serial Numbers
Location:Serial number decal on dashboard.
Electrical
Groundnegative
Charging amps15
Battery volts12
Battery AH45
References
1617 references literature
Owner's Manual for 1600/2400 Series Tractors (98-7171) published in 1984
