Bolens 1886
| | 1971 - 1972 |
| Large Frame Series | | Garden tractor |
|
Series map:
1477
1886
14.0hp
18.0hp
| Production |
| Manufacturer | Bolens
|
| Garden tractor |
| Built in Port Washington, Wisconsin, USA |
| Mechanical |
| Two-wheel drive |
| Steering | manual
|
| | power OptOptional
|
| Disc brakes |
| Open operator station. |
| Tractor hitch |
| Rear Type | 0 OptOptional
|
| Power Take-off (PTO) |
| Rear PTO | independent OptOptional
|
| Clutch | manual *Driven off front PTO
|
| Rear PTO Type | 540/1000 (1.375)
|
| Front PTO | independent
|
| Clutch | manual
|
| Front PTO Type | shaft
|
| Engine RPM | 3600@2000
|
| 1886 Serial Numbers |
| Location: | Serial number plate on top of the engine's heat shield.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 30
|
| Battery volts | 12
|
| Battery AH | 45
|
| References |
 |
| Assembly Instructions Three Point Hitch 18010 (551958) published in 1968 |
| Owner Manual Rear PTO Kit 18095 (552256) published in 1970 |
| Owner Operation Manual 1886 Hydrostatic (552230) published in 1970 |
| Installation Instructions Power Steering Assist Kit (552260) published in 1971 |
| Big tractor published in 1971, by Bolens |
| Service Manual Large Frame Tractors (552665-5) published in 1985 |
