Bolens 1220
| | 1969 |
| Tube Frame Series | | Garden tractor |
|
Series map:
1050
1220
1225
10.0hp
12.0hp
12.0hp
| Production |
| Manufacturer | Bolens
|
| Garden tractor |
| Built in Port Washington, Wisconsin, USA |
| Mechanical |
| Two-wheel drive |
| Differential lock | manual locking hub
|
| Manual steering |
| Open operator station. |
| Power Take-off (PTO) |
| Front PTO | independent
|
| Clutch | manual
|
| Front PTO Type | shaft
|
| | pulley OptOptional
|
| Engine RPM | 3600@3600
|
| 1220 Serial Number Location |
 |
| Serial number plate on the left side of the Bolens 1220 tractor frame, near the clutch/brake pedal. |
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Operator's Manual Husky Tractor Twelve-Twenty (193-01) published in 1968 |
| Husky Tractors published in 1969, by Bolens |
| PTO Pulley Attachment 18704 (551567) published in 1965 |
| Installation Instructions Hydraulic Lift Kit 18703 (552189) published in 1971 |
