Bolens 853
| | 1970 - 1971 |
| Tube Frame Series | | Garden tractor |
|
Series map:
853
1053
8.0hp
10.0hp
| Production |
| Manufacturer | Bolens
|
| Garden tractor |
| Built in Port Washington, Wisconsin, USA |
| Mechanical |
| Two-wheel drive |
| Manual steering |
| Drum brakes |
| Open operator station |
| Power Take-off (PTO) |
| Front PTO | independent
|
| Clutch | manual
|
| Front PTO Type | shaft
|
| | pulley OptOptional
|
| Engine RPM | 3600@3600
|
| 853 Serial Numbers |
| Location: | Serial number plate on the left side of the hood support.
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Operator's Manual Husky Tractor 853 (552166) published in 1970 |
| Bolens Husky published in 1970 |
| Big tractor published in 1971, by Bolens |
| PTO Pulley Attachment 18704 (551567) published in 1965 |
| Installation Instructions Hydraulic Lift Kit 18703 (552189) published in 1971 |
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on June 26, 2026 |
©2000-2026 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
