Craftsman 917.27224


Craftsman 917.27224 lawn tractor photo
2001 - 2002
DLT 2000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Craftsman 917.27224 Engine
20HP Kohler 624cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 917.27224 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Front tire15x6-6
Rear tire20x10-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps15
Battery volts12
References
917.27224 references literature
A Complete Line of 2001 Riding Equipment and Attachments published by Sears
