Ford LS55
| | 1994 - 1995 |
| LS Series | | Garden tractor | | Toro built |
|
Series map:
LS45
LS55
16.0hp
18.0hp
| Production |
| Distributor | Ford
|
| Manufacturer | Toro
|
| Garden tractor |
| The Ford LS55 is similar to the Toro/Wheelhorse 269-H. |
| Variants |
| 9861901 | without cruise control
|
| 9862543 | with cruise control
|
| 268-H | similar Wheel Horse model
|
| Mechanical |
| Two-wheel drive |
| Manual steering |
| Mechanical band brakes |
| Open operator station with adjustable seat. |
| Photos |
| No photos of the Ford LS55 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Power Take-off (PTO) |
| Mid PTO | independent
|
| Clutch | electro-magnetic
|
| LS55 Serial Location |
 |
| Serial number decal located on the fender deck under the tractor's seat. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 15
|
| Battery CCA | 280
|
| Battery volts | 12
|
| References |
 |
| LS Series Yard Tractors published in 1994, by Ford |
| Service Manual LS Yard Tractors (40002550) published in 1995 |
| Page information |
 |
| Copyright 2023 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on March 12, 2022 |
