Lawn Tractors > John Deere > D160

John Deere D160



John Deere D160 lawn tractor photo
2011 - 2017
D100 Series
Lawn tractor
Series map:
D155
D160
D170
24.0hp
25.0hp
25.0hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
Original price$2,599 (2011 )
$2,349 (2015 )
John Deere D160 Engine
25HP Briggs & Stratton 724cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
 2.4 gal*California model
9.1 L
Engine details ...
John Deere D160 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical shoe on transaxle brakes
Open operator station. Adjustable 15-inch tall seat with 5.5-inches of travel in ten positions and lumbar adjustment. Fender-mounted cup holder. Optional nylon sunshade canopy or snow enclosure. Optional 12-volt power outlet.
Photos
John Deere D160
John Deere D160 photos...
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase48.9 inches
124 cm
Weight525 lbs
238 kg
Front tire16x6.5-8
Rear tire22x9.5-12
Full dimensions and tires ...
John Deere D160 attachments
48" mid-mount mower deck
snowblower
blade
Attachment details ...
D160 Serial Numbers
Location:Serial number on rear of tractor, left side, under fender.
2011B100001
2012C300001
2013D400001
2014E500001
2015F600001
2016G700001
2017H810001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps16
Battery volts12
Battery GroupU1
References
D160 references literature
Riding Lawn Tractors published in 2015, by John Deere
Riding Lawn Tractors published in 2017, by John Deere
Riding Lawn Tractors published in 2016, by John Deere
D160 manuals literature
Operator's Manual D100 Series (OMGX24147) published in 2011
Operator's Manual D100 Series (OMGX24230) published in 2012
Operator's Manual D100 Series (OMGX24920) published in 2013
Operator's Manual D100 Series (OMGX25361) published in 2014
Operator's Manual D100 Series (OMGX25410) published in 2014
Operator's Manual D100 Series (OMGX25658) published in 2014
Operator's Manual D100 Series (OMGX26097) published in 2015
Operator's Manual D100 Series (OMUC11804) published in 2016
