Craftsman 917.27610


Craftsman 917.27610 lawn tractor photo
2004
GT 5000 Series
Garden tractor
AYP built
Series map:
917.27609
917.27610
25.0hp
25.0hp
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Garden tractor
Variants
27609gear
27610hydrostatic
Craftsman 917.27610 Engine
25HP Kohler 721cc 2-cyl gasoline
Fuel tank5 gal
18.9 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station
Photos
No photos of the Craftsman 917.27610 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Front tire16x6.50-8
Rear tire23x10.50-12
Full dimensions and tires ...
917.27610 Serial Number Location
Craftsman 917.27610 serial number location
Serial number plate on top of the rear fender deck, below the seat.
Electrical
Groundnegative
Charging amps15
Battery CCA280
Battery volts12
Battery AH35
Battery GroupU1R
References
917.27610 references literature
2004 Riding Equipment published by Sears
