Craftsman 917.27364


No photo available
2004
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Craftsman 917.27364 Engine
18.5HP Briggs & Stratton 503cc 1-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Open operator station
Photos
No photos of the Craftsman 917.27364 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Front tire15x6.0-6
Rear tire20x10-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps9
Battery CCA230
Battery volts12
Battery AH28
Battery GroupU1R
