Ingersoll 3010
|
|
| Production | |
| Manufacturer | Ingersoll |
| Garden tractor | |
| Built in Winneconne, Wisconsin, USA | |
| Ingersoll 3010 Engine | |
| 10HP Kohler 391cc 1-cyl gasoline | |
 Engine details ... |
| Ingersoll 3010 Transmission | |
| hydraulic drive | |
 Transmission details ... |
| Mechanical | |
| Manual steering | |
| Mechanical band brakes | |
| Open operator station. |
| Photos | |
| No photos of the Ingersoll 3010 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 3 gal 11.4 L |
| Hydraulic system | 1.5 gal 5.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 1.5 gal 5.7 L |
| Pressure | 2000 psi (transmission) 137.9 bar |
| 575 psi (lift) 39.6 bar | |
| Valves | 2 |
| Pump flow | 8 gpm 30.3 lpm |
| Tractor hitch | |
| Rear Type | 0 OptOptional |
| Type | sleeve hitch OptOptional |
| Dimensions & Tires | |
| Wheelbase | 46 inches 116 cm |
| Weight | 605 lbs 274 kg |
 Full dimensions and tires ... | |
| Ingersoll 3010 attachments | |
| 38" mid-mount mower deck | |
| 42" mid-mount mower deck | |
| 44" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| 3010 Serial Number Location | |
 | |
| Serial number on the left side of the tractor frame, above the footrest. |
| 3010 Serial Numbers | |
| 1989 | 14124100 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | flywheel alternator |
| Charging amps | 15 |
| Battery CCA | 230 |
| Battery volts | 12 |
| Battery AH | 32 |
| References | |
 | |
| Compact Tractors 3010, 3012, 3014, 4014 (8-55970) published in 1989 |
