Ingersoll 4120



Ingersoll 4120 tractor photo
1992 - 1993
4100 Series
Garden tractor
Series map:
4118D
4120
18.0hp
20.0hp
Production
ManufacturerIngersoll
Garden tractor
Built in Winneconne, Wisconsin, USA
Ingersoll 4120 Engine
20HP Onan 781cc 2-cyl gasoline
Engine details ...
Ingersoll 4120 Transmission
hydraulic drive
Transmission details ...
Mechanical
Two-wheel drive
Power steering
Mechanical band brakes
Open operator station.
Photos
Ingersoll 4120
Ingersoll 4120 photos...
Capacity
Fuel3 gal
11.4 L
Hydraulic system1.5 gal
5.7 L
Hydraulics
Typeopen center
Capacity1.5 gal
5.7 L
Pressure2800 psi
193.1 bar
Rear valves2
Pump flow9.5 gpm
36.0 lpm
Total flow13.75 gpm
52.0 lpm
Steering flow2.25 gpm
8.5 lpm
Steering press.720 psi
49.6 bar
Dimensions & Tires
Wheelbase48 inches
121 cm
Weight723 lbs
327 kg
Front tire16x6.50-8
Rear tire8.00-16
Full dimensions and tires ...
Ingersoll 4120 attachments
44" mid-mount mower deck
48" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
Attachment details ...
4120 Serial Numbers
Location:Serial number plate on the left side of the tractor frame, above the foot rest.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps20
Battery CCA300
Battery volts12
References
4120 references literature
Operator;s Manual Compact Tractors 3118, 4116, 4118, 4120 (8-56800) published in 1992
