Ingersoll 4116
| | 1992 |
| 4100 Series | | Garden tractor |
|
Series map:
4116
4118
16.0hp
18.0hp
| Production |
| Manufacturer | Ingersoll
|
| Garden tractor |
| Mechanical |
| Two-wheel drive |
| Power steering |
| Mechanical band brakes |
| Open operator station. |
| Capacity |
| Fuel | 3 gal
11.4 L
|
| Hydraulic system | 1.5 gal
5.7 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 1.5 gal
5.7 L
|
| Pressure | 2800 psi
193.1 bar
|
| Rear valves | 2
|
| Pump flow | 9.5 gpm
36.0 lpm
|
| Total flow | 13.75 gpm
52.0 lpm
|
| Steering flow | 2.25 gpm
8.5 lpm
|
| Steering press. | 720 psi
49.6 bar
|
| 4116 Serial Numbers |
| Location: | Serial number plate on the left side of the tractor frame, above the foot rest.
|
| Electrical |
| Ground | negative
|
| Charging system | flywheel alternator
|
| Charging amps | 20
|
| Battery CCA | 300
|
| Battery volts | 12
|
| References |
 |
| Operator;s Manual Compact Tractors 3118, 4116, 4118, 4120 (8-56800) published in 1992 |
