Ingersoll 1114 AWS


Ingersoll 1114 AWS tractor photo
1991
1100 Series
Lawn tractor
NOMA built
Series map:
1112
1114
12.0hp
14.0hp
Production
DistributorIngersoll
ManufacturerNOMA
Lawn tractor
Built in Jackson, Tennessee, USA
Ingersoll 1114 Engine
14HP Briggs & Stratton 480cc 2-cyl gasoline
Fuel tank2 gal
7.6 L
Engine details ...
Mechanical
Two-wheel drive
Manual four-wheel steering
Open operator station.
Photos
No photos of the Ingersoll 1114 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Weight375 lbs
170 kg
Front tire15x6.00-6
Rear tire20x10.00-8
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
1114 AWS references literature
Product Portfolie published in 1991, by Ingersoll
