Steiner 410
|
|
| Production | |
| Manufacturer | Steiner |
| Garden tractor | |
| Variants | |
| 75-60001 | 16HP Onan P216G |
| 75-60005 | 20HP Onan P220G |
| Steiner 410 Engines | |
| 16HP Onan 709cc 2-cyl gasoline | |
| 22HP Onan 781cc 2-cyl gasoline | |
| Fuel tank | 5 gal 18.9 L |
 Engine details ... | |
| Steiner 410 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Four-wheel drive | |
| Articulated power steering | |
| Dry disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Steiner 410 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tires | |
| Wheelbase | 39 inches 99 cm |
| Weight | 950 lbs 430 kg |
| Front tire | 20x10.00-8 |
| Rear tire | 20x10.00-8 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Uniquely engineered for unmatched versatility published in 1997, by Steiner |
