John Deere X360 Transmission


John Deere X360 lawn tractor photo
2008 - 2015
Model year
Select X300 Series
Lawn tractor
Series map:
X340
X360
25.0hp
22.0hp
Transmission
TransmissionTuff Torq K58H
Typebelt-driven hydrostatic
Gearsinfinite forward and reverse
Oil capacity3 qts
2.8 L
Oil type
John Deere HY-GARD
(J20D)
Oil change200 h
Speeds
X360 K58H belt-driven hydrostatic speeds
X360 Transmission Controls
John Deere X360 transmission controls
1Throttle
2Brake
3Forward
4Reverse
5Cruise control
6Parking brake
