Ford YT-16 Engine


Ford YT-16 tractor photo
1984 - 1993
Model year
YT Series
Lawn tractor
Gilson built
Series map:
YT-12.5
YT-16
YT-14
12.5hp
16.0hp
14.0hp
Engine Detail
Briggs & Stratton 402707
gasoline
2-cylinder
air-cooled horizontal-shaft opposed-twin
Displacement655 cc
40 ci
Bore/Stroke3.44x2.16 inches
87 x 55 mm
Power (gross)16 hp
11.9 kW
Air cleanerdual element with precleaner
Rated RPM3600
Starter volts12
Oil capacity1.5 qts
1.4 L
Ford YT-16 Engine
Ford YT-16 engine image
Image courtesy of William Richter
