John Deere X305R


John Deere X305R tractor photo
2012 - 2015
Select X300 Series
Rear-discharge mower
Production
ManufacturerJohn Deere
Rear-discharge mower
Built in Horicon, Wisconsin, USA
John Deere X305R Engine
12.2KW Kawasaki 603cc 2-cyl gasoline
Fuel tank2 gal
7.6 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the John Deere X305R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Mid PTO Typepulley
Dimensions & Tires
Weight693 lbs
314 kg
Front tire15x6.00-6
Rear tire20x10.00-8
Full dimensions and tires ...
John Deere X305R attachments
106 cm mid-mount mower deck
snowblower
Attachment details ...
X305R Serial Numbers
Location:2012
2200012013
2500012014
2800012015

FAQ: How to read a serial number table.
Electrical
Groundnegative
Battery volts12
References
X305R references literature
The Complete Range of Lawn Care Solutions published in 2014, by John Deere
