Wheel Horse 212-H Engine
|
|
| Engines overview | |
| 12HP Kawasaki 460cc 1-cyl gasoline | |
| 12HP Briggs & Stratton 465cc 1-cyl gasoline | |
| 12HP Onan 388cc 1-cyl gasoline |
| Engine Detail | |
| Kawasaki FB460V | |
| gasoline | |
| 1-cylinder | |
| air-cooled vertical-shaft | |
| Displacement | 460 cc 28.1 ci |
| Bore/Stroke | 3.50x2.91 inches 89 x 74 mm |
| Power (gross) | 12 hp 8.9 kW |
| Starter | electric |
| Starter volts | 12 |
| Engine Detail | |
| Briggs & Stratton 281707 | |
| gasoline | |
| 1-cylinder | |
| air-cooled vertical-shaft | |
| Displacement | 465 cc 28.4 ci |
| Bore/Stroke | 3.4375x3.0625 inches 87 x 78 mm |
| Power (gross) | 12 hp 8.9 kW |
| Oil capacity | 1.5 qts 1.4 L |
| Oil change | 25 h |
| Wheel Horse 212-H Engine | |
 | |
| Image courtesy of Sorin Lungoci |
| Engine Detail | |
| Onan E125V | |
| gasoline | |
| 1-cylinder | |
| air-cooled vertical-shaft | |
| Displacement | 388 cc 23.7 ci |
| Bore/Stroke | 3.31x2.76 inches 84 x 70 mm |
| Power (gross) | 12 hp 8.9 kW |
| Oil capacity | 1.5 qts 1.4 L |
| Oil change | 25 h |
| Wheel Horse 212-H Engine | |
 |
