Lawn Tractors > Wheel Horse > C-105

Wheel Horse C-105



Wheel Horse C-105 tractor photo
1980 - 1984
C Series
Garden tractor
Series map:
C-85
C-105
C-125
8.0hp
10.0hp
12.0hp
Production
ManufacturerWheel Horse
Garden tractor
Built in South Bend, Indiana, USA
Wheel Horse C-105 Engine
10HP Kohler 391cc 1-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Wheel Horse C-105 Transmission
6-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
Wheel Horse C-105
Wheel Horse C-105 photos...
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Wheelbase45.5 inches
115 cm
Weight590 lbs
267 kg
Front tire16x6.50-8
Rear tire23x8.50-12
Full dimensions and tires ...
Wheel Horse C-105 attachments
36" mid-mount mower deck
42" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
C-105 Serial Numbers
Location:Serial number plate below dash. Model codes shown.
198001-10K801
198101-10K802
198201-10K803
198311-10K801
198411-10K802

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps15
Battery volts12
Battery AH24
References
C-105 references literature
Loader Model 45-08210 published in 1987, by Toro
Wheel Horse published in 1980
Wheel Horse published in 1982
Quality, at an affordable price published in 1984, by Wheel Horse
Operator's Manual B Series C Series (810302R1) published in 1980
