Massey Ferguson 2723H


Massey Ferguson 2723H lawn tractor photo
2006 - 2010
2700 Series
Garden tractor
Simplicity built
Production
DistributorMassey Ferguson
ManufacturerSimplicity
Garden tractor
Variants
Conquest 23/50similar Simplicity model
YT2350similar Snapper model
1723Hsimilar AGCO model
Massey Ferguson 2723H Engine
23HP Vanguard 626cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Differential lockmechanical rear
Steeringmanual
Steeringpower OptOptional
Disc brakes
Open operator station.
Photos
No photos of the Massey Ferguson 2723H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase53 inches
134 cm
Weight711 lbs
322 kg
Front tire16x6.5-8
Rear tire23x10.5-12
Full dimensions and tires ...
Massey Ferguson 2723H attachments
50" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps16
Battery CCA340
Battery volts12
References
2723H references literature
Operator's Manual Prestige / 1800 / 2800 / 500 Series, Conquest / 1700 / 2700 / 400 Series (1735106) published in 2010
