J.I. Case 650
| Production |
| Manufacturer | J.I. Case
|
| Bulldozer |
| J.I. Case 650 Power |
| Engine (gross) | 90 hp
67.1 kW
|
| Engine (net) | 80 hp
59.7 kW
|
| Mechanical |
| Drive | crawler
|
| Final drives | bull gear
|
| Hydraulic wet disc brakes |
| Photos |
| No photos of the J.I. Case 650 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 40 gal
151.4 L
|
| Hydraulic system | 12 gal
45.4 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 12 gal
45.4 L
|
| Pressure | 2200 psi
151.7 bar
|
| Pump flow | 23 gpm
87.1 lpm
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 65
|
| Battery volts | 12
|
| References |
 |
| 650 Dozer published in 1990, by J.I. Case |
