Allis Chalmers TL-40
Series map:
TL-30
TL-40
184.0hp
310.0hp
| Production |
| Manufacturer | Allis Chalmers
|
| Wheel Loader |
| Built in Deerfield, Illinois, USA |
| Allis Chalmers TL-40 Power |
| Engine (gross) | 310 hp
231.2 kW
|
| Mechanical |
| Drive | 4x4 4WD
|
| Final drives | planetary
|
| Pneumatic brakes |
| Open operator station. Cab optional with heater. |
| Photos |
| No photos of the Allis Chalmers TL-40 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 95 gal
359.6 L
|
| Hydraulic system | 77 gal
291.4 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 77 gal
291.4 L
|
| Pressure | 1750 psi
120.7 bar
|
| Pump flow | 110 gpm
416.4 lpm
|
| References |
 |
| TL 40 Tractor Loader published in 1963, by Allis-Chalmers |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on October 29, 2025 |
