Allis Chalmers 840C
|
|
| Production | |
| Distributor | Allis Chalmers |
| Manufacturer | Mitsubishi |
| Wheel Loader | |
| Built in Japan | |
| Allis Chalmers 840C Engine | |
| Mitsubishi 4.4L 6-cyl diesel | |
 Engine details ... |
| Allis Chalmers 840C Transmission | |
| 3-speed power shift | |
 Transmission details ... |
| Allis Chalmers 840C Power | |
| Engine (net) | 83 hp 61.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Articulated power steering | |
| Hydraulic dry disc brakes | |
| Four-post ROPS/FOPS. Cab optional with heater. | |
| Photos | |
| No photos of the Allis Chalmers 840C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 20 gal 75.7 L |
| Hydraulic system | 21.1 gal 79.9 L |
| Hydraulics | |
| Type | open center |
| Capacity | 21.1 gal 79.9 L |
| Pressure | 2350 psi 162.0 bar |
| Pump flow | 29.5 gpm 111.7 lpm |
| Dimensions & Tires | |
| Wheelbase | 96.5 inches 245 cm |
| Weight | 16250 lbs 7371 kg |
| Front tire | 15.5-25 |
| Rear tire | 15.5-25 |
 Full dimensions and tires ... | |
| Allis Chalmers 840C attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| References | |
 | |
| 840C Wheel Loader published in 1982, by Allis Chalmers | |
| 840C 1-1/2 Yd. Loader Specifications published in 1982, by Allis Chalmers |
