Allis Chalmers D 40
| Production |
| Manufacturer | Allis Chalmers
|
| Wheel Dozer |
| Built in Deerfield, Illinois, USA |
| Total built | 64
|
| Allis Chalmers D 40 Power |
| Engine (gross) | 385 hp
287.1 kW
|
| Mechanical |
| Drive | 4x4 4WD
|
| Final drives | planetary
|
| Power steering |
| Pneumatic brakes |
| Open operator station. Cab optional with heater. |
| Photos |
| No photos of the Allis Chalmers D 40 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 95 gal
359.6 L
|
| Hydraulic system | 74 gal
280.1 L
|
| | 77 gal*Capacity with hydraulic pitch and tilt.
291.4 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 74 gal
280.1 L
|
| | 77 gal*Capacity with hydraulic pitch and tilt.
291.4 L
|
| Pump flow | 110 gpm
416.4 lpm
|
| D 40 Serial Numbers |
| Location: | Serial number plate to the left of the operator's seat.
|
| Electrical |
| Ground | positive
|
| Charging system | generator
|
| Batteries | 2
|
| Battery volts | 12
|
| References |
 |
| Operating Instructions and Field Maintenance Model D 40 Tractor Dozer (3038818) |
