J.I. Case 1155E
|
|
| Production | |
| Manufacturer | J.I. Case (a part of CaseIH) |
| Crawler Loader | |
| Built in Schofield, Wisconsin, USA | |
| Variants | |
| 1150E | dozer |
| 1155E | loader |
| J.I. Case 1155E Engine | |
| Case 5.9L 6-cyl diesel | |
 Engine details ... |
| J.I. Case 1155E Transmission | |
| 4-speed full power shift | |
 Transmission details ... |
| J.I. Case 1155E Power | |
| Engine (gross) | 123 hp 91.7 kW |
| Engine (net) | 113 hp 84.3 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | bull gear |
| Hydraulic wet disc brakes | |
| Four-post ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the J.I. Case 1155E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 52 gal 196.8 L |
| Hydraulic system | 15 gal 56.8 L |
| Hydraulics | |
| Type | open center |
| Capacity | 15 gal 56.8 L |
| Pump flow | 40 gpm 151.4 lpm |
| Dimensions & Tracks | |
| Weight | 25000 lbs 11340 kg |
| 15-inch tracks | |
 Full dimensions and tracks ... | |
| J.I. Case 1155E attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Batteries | 2 |
| Battery CCA | 650 |
| Battery volts | 12 |
| References | |
 | |
| 1155E Crawler Loader published in 1990, by J.I. Case |
