CaseIH 258



CaseIH 258 tractor photo
1985 - 1986
Industrial tractor
Series map:
248
258
268
40.0kw
46.2kw
53.7kw
Production
ManufacturerCaseIH
Industrial tractor
Built in Doncaster, England
Variants
595agricultural tractor
CaseIH 258 Engine
CaseIH 3.4L 4-cyl diesel
Fuel tank20.3 gal
76.8 L
Engine details ...
CaseIH 258 Transmissions
8-speed synchromesh
8-speed shuttle
Transmission details ...
CaseIH 258 Power
Engine (gross)62 hp
46.2 kW
Engine (net)58.9 hp
43.9 kW
PTO (claimed)49.2 hp (@540)
36.7 kW
 53.4 hp (max)
39.8 kW
Mechanical
Two-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Power steering
Hydraulic disc brakes
Trailer brakeshydraulic OptOptional
Cab standard with available heater.
Photos
No photos of the CaseIH 258 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2500 psi
172.4 bar
Rear valves2 OptOptional
Pump flow11.9 gpm
45.0 lpm
 18 gpmOptOptional
68.1 lpm
Steering flow2.6 gpm
9.8 lpm
Steering press.1550 psi
106.9 bar
Tractor hitch
Rear TypeII
Controltop link draft sensing
Rear lift4410 lbs
2000 kg
 5250 lbsOptOptional
2381 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear PTO Type540 (1.375)
Engine RPM540@2140
Dimensions & Tires
Wheelbase84.5 inches
214 cm
Weight6000 lbs
2721 kg
Front tire7.50-16
Rear tire16.9/14-28
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
Battery CCA420
Battery volts12
Battery AH95
References
258 references literature
Model 258 published by Case IH
