Caterpillar D5H Series II
Production |
Manufacturer | Caterpillar
|
Bulldozer |
Caterpillar D5H Power |
Engine (gross) | 132 hp 98.4 kW
|
Engine (net) | 120 hp 89.5 kW
|
Mechanical |
Drive | crawler
|
Final drives | single-reduction planetary
|
Two-post ROPS. Cab available with air-conditioning. |
Photos |
No photos of the Caterpillar D5H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity |
Fuel | 65 gal 246.0 L
|
Hydraulic system | 18.5 gal 70.0 L
|
Hydraulics |
Type | load sensing
|
Capacity | 18.5 gal 70.0 L
|
Pressure | 3000 psi 206.8 bar
|
Pump flow | 28.7 gpm 108.6 lpm
|
Electrical |
Charging system | alternator
|
Charging amps | 50
|
Battery volts | 12
|
References |
|
D5H Series II Track-Type Tractor published in 1990, by Caterpillar |
D5H Series II Track-Type Tractor published in 1993, by Caterpillar |
