Caterpillar D4H
|
|
| Production | |
| Manufacturer | Caterpillar |
| Industrial Crawler tractor | |
| Caterpillar D4H Engine | |
| Caterpillar 5.2L 4-cyl diesel | |
 Engine details ... |
| Caterpillar D4H Transmissions | |
| 6-speed gear | |
| 3-speed power shift | |
 Transmission details ... |
| Caterpillar D4H Power | |
| Engine (gross) | 99 hp 73.8 kW |
| Engine (net) | 90 hp 67.1 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | single-reduction planetary |
| Four-post ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the Caterpillar D4H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 44 gal 166.5 L |
| Hydraulic system | 7.8 gal 29.5 L |
| Hydraulics | |
| Type | load sensing |
| Capacity | 7.8 gal 29.5 L |
| Pressure | 2700 psi 186.2 bar |
| Pump flow | 25.5 gpm 96.5 lpm |
| Dimensions & Tracks | |
| Weight | 17769 to 22173 pounds |
| 14-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Charging system | alternator |
| References | |
 | |
| D4H Track-Type Tractor published in 1986, by Caterpillar | |
| D4H Track-Type Tractor published in 1989, by Caterpillar |
