Caterpillar D4G
|
|
| Production | |
| Manufacturer | Caterpillar |
| Industrial Crawler tractor | |
| Caterpillar D4G Engine | |
| Caterpillar 5.0L 6-cyl diesel | |
 Engine details ... |
| Caterpillar D4G Transmission | |
| hydrostatic | |
 Transmission details ... |
| Caterpillar D4G Power | |
| Engine (gross) | 87 hp 64.9 kW |
| Engine (net) | 80 hp 59.7 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | double-reduction outboard planetary |
| Four-post ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the Caterpillar D4G are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 48.6 gal 184.0 L |
| Hydraulic system | 12 gal 45.4 L |
| Hydraulics | |
| Capacity | 12 gal 45.4 L |
| Pressure | 2900 psi 200.0 bar |
| Pump flow | 17.6 gpm 66.6 lpm |
| Dimensions & Tracks | |
| Weight | 17196 to 17952 pounds |
| 18-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
| References | |
 | |
| D4G Track-Type Tractors published in 2001, by Caterpillar |
