Caterpillar D6C
|
|
| Production | |
| Manufacturer | Caterpillar |
| Industrial Crawler tractor | |
| Caterpillar D6C Engine | |
| Caterpillar 10.5L 6-cyl diesel | |
 Engine details ... |
| Caterpillar D6C Transmissions | |
| 5-speed gear | |
| 3-speed power shift | |
 Transmission details ... |
| Caterpillar D6C Power | |
| Engine (net) | 125 hp 93.2 kW |
| Mechanical | |
| Drive | crawler |
| Open operator station. Canopy available. | |
| Photos | |
| No photos of the Caterpillar D6C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 78 gal 295.2 L |
| Hydraulic system | 6 gal (161) 22.7 L |
| 11.5 gal (163) 43.5 L | |
| Hydraulics | |
| Type | open center |
| Capacity | 6 gal (161) 22.7 L |
| 11.5 gal (163) 43.5 L | |
| Pressure | 1725 psi (161) 118.9 bar |
| 1850 psi (163) 127.6 bar | |
| Pump flow | 30 gpm (161) 113.6 lpm |
| 54 gpm 204.4 lpm | |
| Dimensions & Tracks | |
| Weight | 23000 to 23500 pounds |
| 18-inch tracks | |
 Full dimensions and tracks ... | |
| References | |
 | |
| D6C Attachments published in 1969, by Caterpillar | |
| D6C published in 1969, by Caterpillar |
