J.I. Case 750 Loader
|
|
| Production | |
| Manufacturer | J.I. Case |
| Crawler Loader | |
| J.I. Case 750 Loader Engine | |
| J.I. Case 4.4L 4-cyl diesel | |
 Engine details ... |
| J.I. Case 750 Loader Transmission | |
| 4-speed power shift | |
 Transmission details ... |
| J.I. Case 750 Loader Power | |
| Engine (gross) | 70 hp 52.2 kW |
| Mechanical | |
| Drive | crawler |
| Open operator station. | |
| Photos | |
| No photos of the J.I. Case 750 Loader are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 36 gal 136.3 L |
| Hydraulic system | 8.5 gal 32.2 L |
| Hydraulics | |
| Type | open center |
| Capacity | 8.5 gal 32.2 L |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 28.5 gpm 107.9 lpm |
| Dimensions & Tracks | |
| Weight | 18987 lbs 8612 kg |
| 12-inch tracks | |
 Full dimensions and tracks ... | |
| J.I. Case 750 Loader attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| References | |
 | |
| 750 Continuous-Action Loader published in 1964, by J.I. Case | |
| Industrial Tractors and Equipment published in 1965, by J.I. Case |
