John Deere 540B

John Deere 540B industrial tractor photo
1976 - ????
ManufacturerJohn Deere
FactoriesDubuque, Iowa, USA
 Welland, Ontario, Canada
John Deere 540B Engine
John Deere 4.5L 4-cyl diesel
Fuel tank42 gal
159.0 L
Engine details ...
John Deere 540B Power
Engine (gross)96 hp
71.6 kW
Engine (net)90 hp
67.1 kW
Chassis4x4 articulated 4WD
Final drivesinboard planetary
Differential lockhydraulic front and rear
Brakeshydraulic disc
CabFour-post ROPS. Cab optional with heat.
No photos of the John Deere 540B are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeclosed center
Pressure2000 psi
137.9 bar
Pump flow33.4 gpm
126.4 lpm
Dimensions & Tires
Wheelbase106 inches
269 cm
Weight18675 lbs
8470 kg
Full dimensions and tires ...
540B reference literature
JD540-B Grapple Skidder published in 1976, by John Deere
