Ventrac 4520Y
| | 2021 - |
| 4520 Series | | Groundskeeping tractor |
|
| Production |
| Manufacturer | Ventrac (a part of Toro)
|
| Type | Groundskeeping tractor
|
| Original price | $28,765 (2022 )
|
| Ventrac 4520Y Power |
| Engine (gross) | 25 hp
18.6 kW
|
| Mechanical |
| Chassis | 4x4 articulated 4WD
|
| Steering | articulated power
|
| Brakes | mechanical band
|
| Cab | Two-post folding ROPS. Cab optional with available heat.
|
| Photos |
| No photos of the Ventrac 4520Y are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Tractor hitch |
| Rear Type | I OptOptional
|
| Type | Ventrac Mount System
|
| Power Take-off (PTO) |
| Front PTO | independent
|
| Clutch | electrio-magnetic
|
| 4520Y Serial Numbers |
| Location: | Serial number plate on the left side of the front unit, below the steering column.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery CCA | 475
|
| Battery volts | 12
|
| References |
 |
| 4520 published in 2021, by Ventrac |
| Operator's Manual 4520Y (09.10183) published in 2021, by Ventrac |
| Page information |
| Contact: Peter Easterlund |
| Updated on January 22, 2022 |
| Copyright 2022 TractorData LLC |
©2000-2022 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
