John Deere 744E


No photo available
1989 - 1996
Wheel Loader
Production
ManufacturerJohn Deere
TypeWheel Loader
John Deere 744E Engine
John Deere 10.1L 6-cyl diesel
Fuel tank87 gal
329.3 L
Engine details ...
John Deere 744E Power
Engine (gross)260 hp
193.9 kW
Engine (net)250 hp
186.4 kW
Mechanical
Chassis4x4 articulated 4WD
Final drivesinboard planetary
Steeringarticulated power
Brakeshydraulic wet disc
CabFour-post ROPS canopy. Cab available with optional air-conditioning.
Photos
No photos of the John Deere 744E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure3129 psi
215.7 bar
Pump flow82 gpm
310.4 lpm
Dimensions & Tires
Wheelbase134 inches
340 cm
Weight46310 lbs
21006 kg
Front tire23.5-25
Rear tire23.5-25
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Batteries2
Battery volts12
References
744E reference literature
Utility/Construction Purchasing Guide published in 1995, by John Deere
