Tractors > John Deere > 544C

John Deere 544C



John Deere 544C industrial tractor photo
1981 - 1984
Wheel Loader
544B ↑
Series:444C ← 544C → 644C
544D ↓
Production
ManufacturerJohn Deere
TypeWheel Loader
John Deere 544C Engine
John Deere 6.8L 6-cyl diesel
Fuel tank40 gal
151.4 L
Engine details ...
John Deere 544C Transmission
4-speed power shift
Transmission details ...
John Deere 544C Power
Engine (gross)120 hp
89.5 kW
Engine (net)110 hp
82.0 kW
Mechanical
Chassis4x4 articulated 4WD
Final drivesinboard planetary
Steeringarticulated power
Brakeshydraulic wet disc
CabFour-post ROPS with canopy. Cab optional with available air-conditioning.
Photos
No photos of the John Deere 544C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2625 psi
181.0 bar
Pump flow45.8 gpm
173.4 lpm
Dimensions & Tires
Wheelbase102.1 inches
259 cm
Weight21700 lbs
9843 kg
Front tire17.5-25
Rear tire17.5-25
Full dimensions and tires ...
John Deere 544C attachments
front-end loader
backhoe
Attachment details ...
Electrical
Charging systemalternator
Charging amps42
 62 OptOptional
Batteries2
Battery CCA625
Battery volts12
Battery GroupBCI 31
References
544C reference literature
Construction Equipment Purchasing Guide published in 1984, by John Deere
