J.I. Case W-30
|
|
| Production | |
| Manufacturer | J.I. Case |
| Wheel Loader | |
| J.I. Case W-30 Engine | |
| J.I. Case 8.3L 6-cyl diesel | |
 Engine details ... |
| J.I. Case W-30 Transmission | |
| 4-speed power shift | |
 Transmission details ... |
| J.I. Case W-30 Power | |
| Engine (gross) | 165 hp 123.0 kW |
| Engine (net) | 153 hp 114.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Articulated power steering | |
| Hydro-pneumatic disc brakes | |
| Four-post ROPS. Cab optional with available air-conditioning. |
| Photos | |
| No photos of the J.I. Case W-30 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 80 gal 302.8 L |
| Hydraulic system | 48 gal 181.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 48 gal 181.7 L |
| Pressure | 2450 psi 168.9 bar |
| Total flow | 76 gpm 287.7 lpm |
| Dimensions & Tires | |
| Wheelbase | 122 inches 309 cm |
| Weight | 29230 lbs 13258 kg |
| Front tire | 20.5x25 |
| Rear tire | 20.5x25 |
 Full dimensions and tires ... | |
| J.I. Case W-30 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Charging amps | 40 |
| Batteries | 4 |
| Battery volts | 12 |
| References | |
 | |
| W30 Loader published in 1983, by J.I. Case |
