Allis Chalmers HD-41
|
|
| Production | |
| Manufacturer | Allis Chalmers |
| Industrial Crawler tractor | |
| Allis Chalmers HD-41 Engine | |
| Cummins 28.0L 12-cyl diesel | |
 Engine details ... |
| Allis Chalmers HD-41 Transmission | |
| 3-speed power shift | |
 Transmission details ... |
| Allis Chalmers HD-41 Power | |
| Engine | 524 hp 390.7 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | planetary |
| Open operator station. Cab optional. | |
| Capacity | |
| Fuel | 300 gal 1135.5 L |
| Hydraulic system | 52 gal 196.8 L |
| Hydraulics | |
| Type | open center |
| Capacity | 52 gal 196.8 L |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 140 gpm 529.9 lpm |
| Dimensions & Tracks | |
| Weight | 101500 lbs 46040 kg |
| 32-inch tracks | |
 Full dimensions and tracks ... | |
| References | |
 | |
| HD-41 published in 1970, by Allis Chalmers |
