John Deere 355D
|
|
| Production | |
| Manufacturer | John Deere |
| Crawler Loader | |
| John Deere 355D Engine | |
| John Deere 2.9L 3-cyl diesel | |
 Engine details ... |
| John Deere 355D Transmission | |
| 4-speed shuttle | |
 Transmission details ... |
| John Deere 355D Power | |
| Engine (gross) | 50 hp 37.3 kW |
| Engine (net) | 48 hp 35.8 kW |
| Mechanical | |
| Drive | crawler |
| Steering | clutch-brake system |
| Contracting band brakes | |
| Four-post ROPS canopy. Cab optional. | |
| Photos | |
| No photos of the John Deere 355D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 22 gal 83.3 L |
| Hydraulic system | 16.4 gal*Capacity of the reservoir is 6.4 US gallons and the loader system is 10 gallons. 62.1 L |
| Hydraulics | |
| Type | open center |
| Capacity | 16.4 gal*Capacity of the reservoir is 6.4 US gallons and the loader system is 10 gallons. 62.1 L |
| Pressure | 2250 psi 155.1 bar |
| Pump flow | 23 gpm 87.1 lpm |
| Dimensions & Tracks | |
| Weight | 12400 lbs 5624 kg |
| 12-inch tracks | |
 Full dimensions and tracks ... | |
| John Deere 355D attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| 355D Loader published by John Deere | |
| Utility Equipment Purchasing Guide published in 1987, by John Deere |
