| | 1979 - 1981 |
| Industrial tractor |
|
| Transmissions overview |
| 6-speed manual reversing |
| 8-speed gear |
| 4-speed power reversing |
| Transmission |
| Type | manual reversing
|
| Gears | 6 forward and 4 reverse
|
| Clutch | dry disc
|
| Oil capacity | 12.7 qts
12.0 L
|
| Three gears, plus two reverse gears, in high and low ranges. Tractor must be stopped, and clutch used, to shift gear or range. |
| Speeds |
|
| Transmission |
| Type | gear
|
| Gears | 8 forward and 2 reverse
|
| Clutch | dry disc
|
| Oil capacity | 12.7 qts
12.0 L
|
| Four gears, plus reverse, in high and low ranges. Tractor must be stopped, and clutch used, to shift gears or range. |
| Speeds |
|
| Transmission |
| Type | power reversing
|
| Gears | 4 forward and reverse
|
| Oil capacity | 19 qts
18.0 L
|
| Torque-converter transmission with four gears with left-hand reverser lever. Throttle should be placed at idle before shifting gears or direction. |
