J.I. Case 680C Construction King



J.I. Case 680C Construction King industrial tractor photo
1971 - 1974
Industrial tractor
680B ↑
Series:680C Construction King
Production
ManufacturerJ.I. Case
TypeIndustrial tractor
J.I. Case 680C Engine
J.I. Case 4.9L 4-cyl diesel
Engine details ...
J.I. Case 680C Transmission
4-speed power shuttle
Transmission details ...
J.I. Case 680C Power
Engine (gross)84 hp
62.6 kW
Engine (net)74 hp
55.2 kW
Mechanical
Chassis4x2 2WD
Final drivesoutboard planetary
Steeringhydrostatic power
Brakesdrum
CabOpen operator station. Cab optional with heater.
Photos
J.I. Case 680C
J.I. Case 680C photos...
Capacity
Fuel28 gal
106.0 L
Hydraulic system35 gal
132.5 L
Hydraulics
Capacity35 gal
132.5 L
Pump flow27.5 gpm
104.1 lpm
 18 gpm
68.1 lpm
Total flow45.5 gpm
172.2 lpm
Dimensions & Tires
Wheelbase80.5 inches
204 cm
Weight13250 lbs
6010 kg
Front tire11.00Lx16
Rear tire16.9x24
Full dimensions and tires ...
J.I. Case 680C attachments
front-end loader
Attachment details ...
Electrical
Charging systemalternator
Charging amps55
Batteries2
Battery volts12
Battery AH74
