John Deere 5010I
|
|
| Production | |
| Manufacturer | John Deere |
| Industrial tractor | |
| Built in Waterloo, Iowa, USA | |
| Total built | 2007 |
| The primary role of the John Deere 5010I was pulling a model 401 scraper. | |
| John Deere 5010I Engine | |
| John Deere 8.7L 6-cyl diesel | |
 Engine details ... |
| John Deere 5010I Transmission | |
| 8-speed partially synchronized | |
 Transmission details ... |
| John Deere 5010I Power | |
| Engine (net) | 129 hp 96.2 kW |
| Mechanical | |
| Two-wheel drive | |
| Steering | hydraulic power |
| Hydraulic wet disc brakes | |
| Open operator station. | |
| Photos | |
 | |
 John Deere 5010I photos... | |
| Capacity | |
| Fuel | 49 gal 185.5 L |
| Hydraulic system | 16 gal 60.6 L |
| Hydraulics | |
| Capacity | 16 gal 60.6 L |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 25.7 gpm 97.3 lpm |
| Power Take-off (PTO) | |
| Rear PTO | independent (optional) |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 95.5 inches 242 cm |
| Weight | 13550 to 13900 pounds |
| Front tire | 11.00-16 |
| Rear tire | 18.00-25 |
 Full dimensions and tires ... | |
| 5010I Serial Numbers | |
| 1963 | 1000 |
| 1964 | 4500 |
| 1965 | 8000 |
FAQ: How to read a serial number table. | |
| References | |
 | |
| 5010I Tractor published in 1964, by John Deere | |
| 5010 Scraper published in 1965, by John Deere |
