Minneapolis-Moline GTI


Minneapolis-Moline GTI industrial tractor photo
1938 - 1941
Industrial tractor
Production
ManufacturerMinneapolis-Moline
TypeIndustrial tractor
FactoryMinneapolis, Minnesota, USA
Total built1,200
Variants
GTfarm tractor
GTIindustrial tractor
Minneapolis-Moline GTI Engine
Minneapolis-Moline 6.6L 4-cyl gasoline
Fuel tank30 gal
113.6 L
Aux. fuel4 gal
15.1 L
Engine details ...
Minneapolis-Moline GTI Power
Drawbar (claimed)47.8 hp
35.6 kW
Plows4-5
Mechanical
Chassis4x2 2WD
Steeringmanual worm-and-sector
Brakesmechanical band
CabOpen operator station.
Tractor hitch
Drawbarheavy-duty swinging drawbar
Power Take-off (PTO)
Rear RPM526 (1.375)
Dimensions & Tires
Wheelbase84 inches
213 cm
Weight10,000 lbs
4536 kg
Front tire7.50x18
Rear tire11.25x28
Full dimensions and tires ...
Belt Pulley
Diameter16 inches
40 cm
Width7.5 inches
19 cm
RPM650
Speed2,720 ft/min
829.06 meters/min
