Massey Ferguson 30
| | 1970 - 1976 |
| Industrial tractor |
|
| Production |
| Manufacturer | Massey Ferguson
|
| Type | Industrial tractor
|
| Variants |
| 30 | industrial
|
| 30T | turf tractor
|
| Massey Ferguson 30 Power |
| Engine | 61 hp
45.5 kW
|
| Diesel Drawbar (claimed) | 45 hp
33.6 kW
|
| Gas Drawbar (claimed) | 44 hp
32.8 kW
|
| PTO (claimed) | 52 hp
38.8 kW
|
| Mechanical |
| Chassis | 4x2 2WD
|
| Steering | power
|
| Brakes | disc
|
| Cab | Two-post ROPS. Four-post ROPS canopy and cab optional.
|
| Capacity |
| Fuel | 18.5 gal
70.0 L
|
| Hydraulic system | 6 gal
22.7 L
|
| Steering | 1.67 qts
1.6 L
|
| Hydraulics |
| Capacity | 6 gal
22.7 L
|
| Pressure | 2125 psi
146.5 bar
|
| Total flow | 20 gpm
75.7 lpm
|
| Steering cap. | 1.67 qts
1.6 L
|
| Tractor hitch |
| Rear Type | optional
|
| Power Take-off (PTO) |
| Rear PTO | live *Two-stage clutch
|
| Rear RPM | 540
|
| References |
 |
| Buyer's Guide published in 1973, by Massey Ferguson |
| Page information |
| Contact: Peter Easterlund |
| Updated on January 17, 2021 |
| Copyright 2021 TractorData LLC |
