Allis Chalmers I40
|
|
| Production | |
| Manufacturer | Allis Chalmers |
| Industrial tractor | |
| Built in West Allis, Wisconsin, USA | |
| Variants | |
| D10 | ag tractor |
| Allis Chalmers I40 Engine | |
| Allis-Chalmers 2.4L 4-cyl gasoline | |
| Fuel tank | 12.5 gal 47.3 L |
 Engine details ... | |
| Allis Chalmers I40 Transmissions | |
| 4-speed gear | |
| 4-speed shuttle | |
| 8-speed | |
 Transmission details ... |
| Allis Chalmers I40 Power | |
| Engine (gross) | 40.6 hp 30.3 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | bull gear |
| Power steering | |
| Mechanical drum brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Allis Chalmers I40 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2000 psi 137.9 bar |
| Total flow | 17 gpm 64.3 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1650 |
| Dimensions & Tires | |
| Wheelbase | 78.75 inches 200 cm |
| Weight | 3980 to 7400 pounds |
| Front tire | 7.50x16 |
| Rear tire | 14.9x24 |
 Full dimensions and tires ... | |
| Allis Chalmers I40 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| References | |
 | |
| I-40 Gasoline published in 1965, by Allis Chalmers |
